Maintenance and Specs for your Pile Brush
Timing Belt
Sand Trap
Finger Lift
STORAGE
After using your pile brush always empty the sand
trap and check the refill bag and cord.
Wrap the cord around the cord rest and the
handle.
When not in use, do not leave weight of
machine resting on brush. Place a block or the
corraguted material from shipping, under the
machine away from brush.
(It will flat-spot its fibers, which causes vibration, poor clean-
ing and premature brush replacement.)
Avoid wet carpeted areas. (This is not good for
the natural fiber brush, vacuum bag and motor, or its drive
system.)
Store the pile brush in a dry area.
Brush
Sand Trap
Soild Vegetable
Brush
Power Switch
Heavy C-Tex Outer Bag
Cord Wrap
Clamp Lever
Certified Dry Extraction Pile Lifter Specs:
WEIGHT: 67 lbs.. (30.4 kilo)
OVERALL WIDTH: 19.25” (48.90 cm)
OVERALL DEPTH: 18” (45.72 cm)
OVERALL HEIGHT: 43.25” (109.86 cm)
BRUSH DRIVE MOTOR: 1/2 hp, 60Hz, 115 volt
BRUSH LENGTH: 15” Self-Leveling (38.10 cm)
BRUSH DIAMETER: 4.5” (10.16 cm)
Choice of two brushes: Solid reversible Vegetable fill, Tufted nylon
VACUUM MOTOR: 1/2 hp universal 115 volt
BASE: Polished rugged aluminum casting
CABLE: 50’ x 14.3 U.L. approved
SWITCH: Momentary contact
GEARED DRIVE: No slipping
OUTER BAG: Heavy C-Tex™ material
(Collection efficiency 97.25% @ 0.3 microns)
SAND TRAP: Exclusive hinged sand trap on bottom of base
to collect heavy objects from passing through
vacuum motor.
WHEELS: 4” heavy duty, non-marking
FLOOR ROD: Heavy 1/4” (32 cm) wall tubing fully adjustable
HANDLE: Extra wide 18” (45.72 cm)
SWITCH LEVER: 5” (12.7 cm) plastic coated finger tip control
SHIPPING WEIGHT: 80 lbs.. (36.3 kilo)
Vacuum Motor
Drive Motor
Handle
Rubber Bumper
Tufted Nylon
Brush
Belt Guard
1
Corrugated 2x4 Block
