Pile Brush Handle Assembly - Includes
1 900-078 Switch Box Cover Casting 1
2 900-077 Switch Box Back Casting (has 3 thru holes) 1
**905-002 Bottom Switch Box Screw 2
**905-019 Top Switch Box Screw 1
3. 929-006 Plastic Handle Grip 2
4. 946-005 Dust Bag Support Ring 1
5. 957-008 2” Floor Rod & Yoke 1
6. 938-001 Plastic Handle Bushing 2
7. 921-041 Power Cable w/Plug 1
8. 915-051 Cable Wrap 1
9. 915-052 Cable Wrap Clamp 1
10 903-007 1/4-20 x 3/4 Rd. Hd. Screw 2
11 908-004 1/4-20 Hex Nut 2
43 930-008 Handle Bar 1
44 904-034 Handle Bar Screws 1/4-20 x 1-1/2 2
47 900-092 Switch Lever Casting 1
48 901-016 3/16 x 1-1/2 Spiral Pin 2
49 907-023 3/16 id Spiral Pin Washer 1
50 946-010 Motor Drive Switch Auxiliary Spring 1
51 920-008 Motor Drive Switch 1
52 903-015 Motor Drive Switch Screws 2
53 915-036 Motor Drive Mounting Bracket 1
54 903-020 10-32 x 3/8 Rd. Hd. Screw - S 3
55 906-004 #10 Lock Washer 2
57 922-062 #10 Butt Wire Connector 1
58 922-060 Acorn Nut Wire Connector 1
59 913-002 3/8 x 1/2 Strain Relief Tubing 1
60 921-009 Floor Rod Electric Cable w/Plug 1
62 910-002 Allen Head Cap Screw 2
19 910-005 Floor Rod Base Bolt 1
17 907-002 3/8 Wrought Steel Washer - Small 2
21 908-002 3/8-16 Essna Lock Nut 1
27 906-001 1/4” Lock Washer 2
101-014 2” FLOOR ROD CLAMP ASSEMBLY
12 900-147 2” High Floor Rod Clamp Casting (for 1-1/4” dia.) 1
13 902-001 Cam Thrust Bolt 1
20 907-009 3/8 Wrought Steel Washer 1
21 908-002 3/8-16 Essna Lock Nut 1
37 915-003 Clamp Cam Lever 1
98 902-002 5/16-18 x 1 Clamp Cam Lever Bolt 1
99 908-005 5/16-18 Clamp Cam Lever Lock Nut 1
17 907-002 3/8 Wrought Steel Washer - Small 1
101-016 AXLE ASSEMBLY
14 943-001 Axle 1
16 927-0104 Non-Marking Wheels (3/8 i.d.) 2
17 907-002 3/8 Flat Washer 6
18 942-004 Axle Hub Cap 2
**939-024 Large Axle X Ring 2
**939-023 Small Axle X Ring 2
68 924-024 ZIPPER BAG - TOP FILL (HIGH EFFICIENCY)
**924-058 High Efficiency Paper Bag Inserts 3/pkg (fits #924-024 bag only) 1
**924-056 Paper Bag Inserts 3/pkg. (fits bottom fill bag only) 1
**946-011 Paper Bag Support Ring 1
**924-002 Shake Down Dust Bag discontinued
**935-001 Clamp, Chain & Hook Assem. (for original shake down bag)
Drawing Part Number
Number Number Description Required
4
