CS-2 Tubing Connec ons
1. Measure and cut a length of 1/4" or 3/8" tubing (depending on model) long enough to reach from the faucet to the
faucet connector on the system. Connect one end to the faucet nipple using a jaco nut and plas c insert. Connect the other
end to the faucet connec on on the post-fi lter suing a jaco nut and plas c insert.
2. Measure and cut the length of 1/4" tubing long enough to reach from the feed water supply to the inlet. Connect the
end to the feed inlet on the prefi lter using a jaco nut and plas c insert. See Fig. 5.
3. Connect one end of a 3/8" length of tubing to the tank valve. Insert the other end fi rmly into the quick-connect cross on
the shut-off valve.
4. Connect the 1/4" tubing from the faucet to the white swivel with yellow collet on the membrane desalinator.
5. Connect the free end of the 3/8" drain tubing to the drain connec on.
Fig. 5
INSERT
FERRULE
COMPRESSION NUT
TUBING
