３．Operating Instruction（How to adjust each part）
（１）How to skive
① Turn on the main power on the back of the machine.（When the power is on, the indicator lamp
lights up in green.）
② Adjust the guide to the desired width.
③ Adjust the presser foot to the desired thickness（Refer to the following for the operation method）
④ Turn on the power switch.
⑤ Feed the material between the feed roller and the presser foot while keeping it along the guide.
（ 2 ）Thickness adjustment・Presser foot handle set
Turn the thickness adjustment screw to the right, the presser foot approaches the blade.
Turn to the left, wider distance from the blade. (The presser foot moves up and down by 1
mm in one rotation.)
By raising and lowering the presser handle, it is possible to raise and lower the presser foot
with one touch without changing the thickness adjustment.
When skiving from the middle of workpiece or workpiece gets between feed roller and the
blade, it is useful for removal work.
① When skiving thinly
The thickness adjusting screw is turned on the right direction.
② When skiving thickly
The steps of ① above should be performed in reverse order(left direction).
