（ 7 ）Position adjustment of spring tension adjustment lever
① When a hard workpiece is skived
Pull the spring tension adjustment lever forward and hang in the back groove, strengthen the
force of the spring.
② When a soft workpiece is skived
Hang in the front groove of the spring tension adjustment lever, weaken the force of the spring.
( 8 ) Removing the feed holder frame
① Pull out the dust box.
② Hook the spring tension adjustment lever on the side of the stopper.
③ Loosen the screws of inner cover with the accessory driver and remove the cover.
④ Loosen the center set screw with the accessory hex wrench and pull the center pin
sideways while supporting the feed support frame with your hand, the feed support frame
will be removed.
⑤ After pulling out the feed support frame, disconnect the feed motor harness from the
connector.
⑥ Assemble in the reverse process.
