Appendix D
Fastener Torque Specifications
Correct tightening torque of threaded fasteners is very important to your
safety. Always tighten fasteners to the correct torque. In case of a conflict
between the instructions in this manual and information provided by a
component manufacturer, consult with your dealer or the manufacturer’s
customer service representative for clarification. Bolts that are too tight
can stretch and deform. Bolts that are too loose can move and fatigue.
Either mistake can lead to a sudden failure of the bolt.
Always use a correctly calibrated torque wrench to tighten critical
fasteners on your bike. Carefully follow the torque wrench manufacturer’s
instructions on the correct way to set and use the torque wrench for
accurate results.
FASTENER RECOMMENDED TORQUE
Headset/Handlebar
Threaded Headset Locknut 16-24 Nm (142-212in-lb)
Stem Expander Bolt (quill type) 17-22 Nm (150-195in-lb)
Handlebar Binder Bolt (quill type) 17-22 Nm (150-195in-lb)
Stem Binder Bolt (threadless) 13.5-16 Nm (120-144in-lb)
Compression Cap 2-3 Nm (20-26in-lb)
Stem Faceplate Bolts 13.5-19 Nm (120-168in-lb)
Pedals/Bottom Bracket
Pedal 34.5-40 Nm (307-354in-lb)
Wheels
Axle Nut 30-42 Nm (260-372in-lb)
Seat
Seat Post Binder 4-6.5 Nm (36-60in-lb)
Seat Rail Binder 18-34 Nm (160-300in-lb)
Derailleur/Shifting
Shift Lever – Twist Grip 6-8 Nm (53-70in-lb)
Rear Derailleur Mounting Bolt 8-10 Nm (70-86in-lb)
Rear Derailleur Cable Pinch Bolt 4-5 Nm (35-45in-lb)
Rear Derailleur Pulley Wheel Bolt 3-4 Nm (27-36in-lb)
Brakes
Disc Brake Rotor To Hub 4-7 Nm (36-60in-lb)
Disc Brake Caliper Mount 6-9 Nm (52-84in-lb)
Brake Caliper Mount to Frame (side/dual/centerpull) 8-9.5 Nm (70-85in-lb)
Brake Caliper Mount to Braze-on Linear Pull/Cantilever 5-7 Nm (44-60in-lb)
Brake Pad (Threaded Stud, Dual Pivot/Cantilever/Sidepull) 5-7 Nm (44-60in-lb)
Brake Pad (Smooth Stud, Cantilever) 8-9 Nm (70-78in-lb)
Brake Cable Pinch Bolt (Linear Pull/Cantilever) 6-8 Nm (53-69in-lb)
Brake Cable Pinch Bolt (Sidepull/ Dual Pivot/Centerpull) 6-8 Nm (53-69in-lb)
Brake Caliper Arm Pivot (Dual Pivot) 8-9.5 Nm (70-85in-lb)
Sidepull/Dual Pivot Brake Pad Bolt 5-7 Nm (44-60in-lb)
Cantilever Straddle Wire Pinch 5 x 0.8 Thread 4-5 Nm (35-43in-lb)
Brake Caliper Wire Pinch Linear Pull/Cantilever M6 x1 Thread 5.5-8.5 Nm (50-75in-lb)
Brake Lever (MTB type) 6-8 Nm (53-69in-lb)
Brake Lever (Drop Bar Type) 6-8 Nm (53-69in-lb)
Fenders
Fender Bolts 6-9 Nm (53-78in-lb)
Fender Brace Bolts 2.5-4 Nm (25-35in-lb)
Banana Seat
Sissy Bar Bolts 2.5-4 Nm (25-35 in-lb)
Bike Basket
Base Clip Bolts 2.5-4 Nm (25-35ft-lb)
Mount Bracket Bolts 2.5-4 Nm (25-35ft-lb)
Strut Bolts 2.5-4 Nm (25-35ft-lb)
Training Wheels
Support Bracket Bolt 20 Nm (177in-lb)
