1 PRESENTATION
This installation guide gives you all information :
- To install the computer Gyropilot 2
- To install rudder angle sensor
- To install de the hydraulic unit
- To get the optimal performances from your pilot and your boat.
See the installation guide for fluxgate compass and multifonction Gyrographic.
Installation architecture
The presence of the equipment in the following diagram is for information only, and does
not represent the equipment of your installation.
nke Gyrop
i
lot 2
CRP
RVP
RVP
Calculateur Gyro2
Bus
Angle
Barre
Tiller
Embrayage
Alim.
Pompe
réversible
TOPLINE câble
20-61-001
GND
DATA black
12VDC white
Figure 1
loch depth interface
90-60-450
loch
speedomètre
depth
Connecting box
90-60-417
NMEA -
NMEA +
Input NMEA
1
1
Auto
Stop
Page
Ent
True wind mode
G5
Reference True wind
Rudder angle
0
-10 10
-30°
-30°
Gyropilote Graphic
nke
M
nke
Helm spindle
Rudder angle
hydaulic ram
Masthead unit
