NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M60 Tow Tractor Manual No. 46050
PAGE 8
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
2 OPERATION
2.5 SHUTTING DOWN THE TRACTOR
1. Bring tractor to a safe and complete stop and set parking brake.
2. Place gear shift lever in neutral (N).
Be sure that the shift control lever is secure in the neutral detent
and the parking brake is applied to prevent unintended movement that could result
in serious injury or death.
3. Turn o all lights.
4. Turn o ignition switch.
Always set the parking brake when parking the machine. The
transmission does not have an internal parking lock and failure to apply the parking
brake could allow unexpected movement resulting in crushing injury or death.
2.6 MASTER DISCONNECT SWITCH
Some tractors are equiped with a master disconnect electrical switch located in the
engine compartment and operated with a outside handle. With the handle in the
straight up position the switch is closed. Turn CW 90 degrees to open the switch.
2.7 EMERGENCY STOPPING
If the brakes fail, follow this procedure:
1. Downshift to next lower gear, unless already in “1.”
2. Use parking brake to stop tractor by pulling on parking brake lever.
2.8 TOWING THE TRACTOR
NOTICE! Tow the tractor with the rear end picked up or with the drive shaft
disconnected. Failure to do so will damage the transmission.
IN AN EMERGENCY, the tractor may be towed without lifting the wheels or
disconnecting the drive shaft IF:
• Engine is running AND transmission is in neutral.
• Towing distance must be LESS THAN 1 MILE and travel speed LESS THAN
5 M.P.H.
Failure to follow these instructions will cause transmission damage and will
void the warranty.
JULY 01, 2015
Property of American Airlines
