PAGE 1-9
CHAPTER 2 MAINTENANCE
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
1 SERVICING
SEPTEMBER 01, 2015
Every 500
Hours or 6
months
Check security of wiring, ties, and clamps.
Check condition of lamps and security of xtures.
Operate all normal overrides on directional solenoid valve
(in hydraulic package). Check for sticking valve spool or
override plungers. Replace valve if found defective.
Give system a complete functional check using controls
at both operator station and platform.
Check interlocks as described in Chapter 1
Check instrument panel and platform control switches for
waterproof sealing integrity and good mechanical and
electrical condition
Check toggle switches on instrument panel (especially
Stabilizer and Platform) for damage to the red sealing
boots at base of toggle. Also, inspect Engine On/O/
Start toggle switch on platform pendant control. Close
visual examination is required. Move toggles to various
positions and check for deterioration of boot. Replace
complete switch if found defective.
Check platform pendant station for damage to exible
push button membranes. Operate push button switch and
check for obvious deterioration of membranes. Replace
complete push button station if found defective.
Lubricate, using #10 general-purpose oil:
Fig 2, 3
Control Linkage 4.3.11, 4.3.15
Stabilizer cylinder pins
Fig 3
Engine cover hinge
Operator seat adjustment lever
Lubricate, using multi-purpose graphite-based grease:
Fig 2
Cam roller channels
Fig 2
Steering knuckles and tie rod ends
Fig 2
Lube & check security, driveshaft universal joints
Fig 3
Lube & check security, Lift cylinder attach pins
Fig 2
Lube & check security, Scissors aft pivot pins
Fig 2
Lube & check security, Scissors center pivots
Fig 2
Inspect structural condition of chassis, scissors, and
platform
Every 3,000
Hours or
Yearly
Change oil in dierential 1.3
Grease front wheel bearings using all-purpose bearing
grease. Refer to the Spicer Axle manual in Chapter 5.
Fig 2
Grease handbrake switch. Fig 3
