PAGE 1-6
CHAPTER 2 MAINTENANCE
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
1.5 FLUIDS AND CAPACITIES AND AMBIENT TEMPERATURE RANGES
The Maintenance Lift can be operated over a wide range of ambient temperatures
if the following uid recommendations are used.
1.5.1 Fluid Req. Engine, Trans., Axle, Brake and Hyd. System
ENGINE REQUIREMENTS FOR AMBIENT TEMPERATURE RANGES
Item Ambient Temp. Specication Capacity
Engine
Coolant
(Liquid cooled
engines only)
-25°F and above
-32°C and above
50/50 ethylene glycol antifreeze/water
mixture ASTM4985 GM6038M specs.
14 Qts
[13.25 L]
-26°F to -65°F
-33°C to -54°C
62/38 ethylene glycol antifreeze/water
mixture ASTM4985 GM6038M specs.
Engine Fuel
(Cummins)
32°F and above
0° C and above
ASTM number 2D (Diesel)
19.5 gal
[74 L]
32°F and below
0°C and below
Winter blended fuel such as found at
commercial fuel-dispensing outlets
which are combinations of 1D and 2D
diesel fuels.
Engine Fuel
(Deutz)
0°C and above ASTM number 2D (Diesel)
19.5 gal.
[74L]
0°C to -20°C Winter blended fuel such as found
at commercial fuel-dispensing
outlets which are combinations of
1D and 2D diesel fuels.
-20°C and below Add % paran to winter or summer
grade fuels per Deutz Operation
Manual, Operating Media section.
Engine Fuel
(All gas
engines)
All Regular unleaded gasoline. 19.5 gal.
[74L]
Engine Oil
(Cummins)
24°F and above
-5°C and above
15W-40 API CH-4/SJ classication Pan only:
15qt
[14.2 L]
Total sys:
17 qt.
[16.4L]
23°F to -10°F
-5°C to -24°C
10W-30 API CH-4/SJ classication
-9°F and below
-23°C and below
Synthetic 5W-30 with API CH/SF or
higher classication
Engine Oil
(Deutz)
-5°C and above SAE 20W-50 12 qts
[11.35L]
-20°C to 40°C SAE 10W-40
-35°C to 30°C SAE 0W-30
-35°C and below Preheat oil by storing in warm storage
1 SERVICING
SEPTEMBER 01, 2015
Property of American Airlines
