NMC-WOLLARD TML-704H Maintenance Manual

PAGE 2-15
CHAPTER 2 MAINTENANCE
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
2 TROUBLE SHOOTING
SEPTEMBER 01, 2015
Code
Number
Probable Cause Test/Remedy
M1 Engine belt slipping or
broken
Check belt tension, adjust or replace if
required.
M2 Footbrake linkage out
of adjustment
Readjust linkage
M3 Broken, perforated or
loose fuel line between
tank and engine
Visually inspect and vacuum test fuel line.
Repair or replace as necessary.
M4 Control rods out of
adjustment or
damaged
Check, repair or readjust as required.
M5 Transmission linkage
out of adjustment
Check and readjust.
M6 Throttle linkage out of
adjustment
Readjust linkage.
M7 Accelerator linkage out
of adjustment
Readjust linkage.
M8 Tie rod ends defective Check for free play; replace as required.
M9 Linkage broken Check and repair or replace as required.
M10 Linkage seized Check, clean/lubricate or repair.
M11 Handbrake cable
linkage out of
adjustment
Readjust linkage.
M12 Fuel lter clogged Clean lter.
M13 Axle U-bolts loose Tighten U-bolts.
M14 Drive shaft universal
joints loose
Replace as required.
M15 Return spring broken Replace spring.
M16 Cam rollers seized Check, clean/lubricate, repair or replace.
M17 Pivot bearing seized Check, clean/lubricate or replace.
M18 Scissor mechanism
damaged, out of
alignment
Check alignment, straighten or repair any
damage
M19 Bearings defective Inspect and replace as required.
2.10 PROBABLE CAUSES/REMEDIES BY CODE: HYDRAULIC/STRUCTURAL
Property of American Airlines
