PAGE 3-5
CHAPTER 2 MAINTENANCE
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 P: 715-835-3151● F: 715-835-6625 www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
3 REMOVAL AND INSTALLATION
1. Install ex plate (6) and support ring (5) on engine using hex head bolts
(27).
2. Install dowel pins (14) in adapter plate (4).
3. Align torque converter studs with corresponding holes in ex plate (6).
At the same time, align transmission to the dowel pins and secure to the
adapter plate (4) using supplied bolts (12) and lock washers (13).
4. Install nuts (8) to torque converter studs after transmission is securely
bolted to engine. Access studs through inspection hole in ywheel
housing.
5. Install speedometer gear (19) on shaft.
6. Install universal joint yoke (20) on shaft and secure using nut (21).
7. Install speedometer cable access plug (16) in hole as shown.
8. Remove kickdown arm (24) and reinstall 180-degrees from original
position.
9. Paint dipstick tube (17) black–outside only.
10. Place O-ring (18) on grooved end of dip stick tube (17).
11. Remove plastic plug and rmly insert tube (17) in hole until seated.
12. Install vent tube (26). Do not overtighten!
13. Paint the steel part of the tail housing black.
SEPTEMBER 01, 2015
Property of American Airlines
