Catalog Designation for Phase barrier for withdrawable type
Catalog Designation for Door interlocks for withdrawable type
Catalog Designation for Mechanical Interlocks with cables
VPEC 12 N S
I II III IV
I VPEC: Door interlocks for withdrawable type
II 12: For 3200A PCB
III N: UL
IV
P: Position interlock
S: Status interlock
IPA 12 N
I II III
I IPA: Mechanical Interlocks with cables
II 12: For 3200A PCB
III N: UL
DPS 12 N 2
I II III IV
I DPS: Phase barrier for withdrawable type
II 12: For 3200A PCB
III N: UL
IV
2: 2 pcs for 3P
3: 3 pcs for 4P
Selection Guide Selection Guide
Catalog Designation for Position indicator
EF 12 N
I II III
I EF: Position indicator
II 12: For 3200A PCB
III N: UL
Catalog Designation for OFF position keylock
KLK 12 N 1
I II III IV
I KLK: OFF position keylock
II 12: For 3200A PCB
III N: UL
IV 1: 1 lock 1 key, 2: 2 locks 1 key, 3: 3 locks 2 keys
Catalog Designation for Doorframes for fixed type
Catalog Designation for Doorframes for withdrawable type
CDP 12 N
I II III
I CDP: Doorframes for fixed type
II 12: For 3200A PCB
III N: UL
DDP 12 N
I II III
I DDP: Doorframes for withdrawable type
II 12: For 3200A PCB
III N: UL
Catalog Designation for Phase barrier for fixed type
PHS 12 N 2
I II III IV
I PHS: Phase barrier for fixed type
II 12: For 3200A PCB
III N: UL
IV
2: 2 pcs for 3P
3: 3 pcs for 4P
Catalog Designation for Pushbutton lock device
VBP 12 N
I II III
I VBP: Pushbutton lock device
II 12: For 3200A PCB
III N: UL
Catalog Designation for External current transformer for Neutral
NCT 12 N
Ⅰ Ⅱ Ⅲ
Ⅰ NCT: External Current transformer for Neutral
Ⅱ 12: For 3200A PCB
Ⅲ N: UL
Catalog Designation for Energy-Limiting Maintenance Switch (ELM Switch)
ELM 10
Ⅰ Ⅱ
Ⅰ ELM: Energy-Limiting Maintenance Switch
Ⅱ 10: For UL PCB
Catalog Designation for Lockable switch cover for ELM Switch
LSC 10
Ⅰ Ⅱ
Ⅰ LSC: Lockable switch cover for ELM Switch
Ⅱ 10: For UL PCB
Note: LSC10 is an optional unit, please comment if it is required when purchasing.
