Noark A32 - Product Parameters; Environmental Conditions

User Manual 07User Manual 06
Product parameters
Type A32Q A32R A32H ASD32Q ASD32R ASD32H
Pole 3P/4P 3P/4P
Installation Fixed/Withdrawable Fixed/Withdrawable
Rated current(A) 800/1600/2000/2500/3200
Fixed：800/1600/2000/2500
Withdrawable：
800/1600/2000/2500/3200
Rated Maximum Valatge(V) 254/508/635 254/508/635
Frequency(Hz) 50/60 50/60
Interrupting rating at rated maximum voltage (kA)
254V 65 85 100 / / /
508V 65 85 100 / / /
635V 65 85 100 / / /
Short time withstand current (kA)
254V 65 85 100 65 85 100
508V 65 85 100 65 85 100
635V 65 85 100 65 85 100
operating time(ms)
open ＜70 ＜70
close ＜40 ＜40
life cycle(time)
mechanical
without maintenance 10000 10000 10000 10000 10000 10000
with maintenance / / / / / /
electrical
without maintenance 6000 6000 6000 6000 6000 6000
with maintenance / / / / / /
Enclosure dimension
H×W×D(in/mm)
withdrawable
3P
21.65×23.62×18.11
(550×520×460)
Ventilation Area Top: 9092mm²
Bottom：9092mm²
21.65×23.62×18.11
(550×520×460)
Ventilation Area Top: 9092mm²
Bottom: 9092mm²
4P
21.65×25×18.11
(550×635×460)
Ventilation Area Top: 11963mm²
Bottom: 11963mm²
21.65×25×18.11
(550×635×460)
Ventilation Area Top: 11963mm²
Bottom: 11963mm²
fixed
3P
21.65×20.47×14.17
(550×520×360)
21.65×20.47×14.17
(550×520×360)
4P
21.65×25×14.17
(550×635×360)
21.65×25×14.17
(550×635×360)
Mounting type Rated current/A Power Consumption/W
Withdrawable
800 80
Withdrawable
1600 300
Withdrawable
2000 400
Withdrawable
2500 500
Withdrawable
3200 620
Fixed 800 50
Fixed 1600 200
Fixed 2000 250
Fixed 2500 300
Fixed 3200 430
A32 Bus bar recommendation
In
Vertical Horizontal
Qty Size(in) Size(mm) Qty Size(in) Size(mm)
800A 1 1/4×3 6.35×76.2 1 1/4×3 6.35×76.2
1600A 2 1/4×3 6.35×76.2 2 1/4×3 6.35×76.2
2000A 2 1/4×4 6.35×101.6 3 1/4×3 6.35×76.2
2500A 3 1/4×4 6.35×101.6 5 1/4×3 6.35×76.2
3200A 4 1/4×4 6.35×101.6
Recommended tighting torque is 40-50 N.m.
Note: These tables should be used as a general guideline only, the solution used should take into consideration the varieties of switchgear types and conditions.
Environmental Conditions
Ambient temperature
Altitude
Humidity
Rated
Current(A)
Temperature(℃ )
<40 45 50 55 60 65 70
800 100% 100% 100% 100% 100% 100% 100%
1600 100% 100% 100% 100% 100% 100% 100%
2000 100% 100% 100% 100% 100% 100% 93%
2500 100% 95% 92% 88% 83% 80% 75%
3200 100% 95% 92% 88% 83% 80% 75%
Altitude(m)
<2000 2600 3900 4900
Rated Voltage(V) 1xUe 0.95xUe 0.8xUe 0.7xUe
Rated Current(A) 1xIn 0.99xIn 0.96xIn 0.94xIn
A32 Circuit breakers can operate in the following environmental conditions:
With M Smart Unit: -40℃ ~ 70℃;
With H Smart Unit: -20℃ ~ 70℃;
A32 Circuit breakers can operate at higher temperatures than the reference temperature 40℃,in this case,the derating coefficients
shown in the table must be applied.
A32 Circuit breakers do not undergo changes in rated performance up to 2000m.Beyond this altitude ,the derating coefficients shown in
the table must be applied.
The relative humidity does not exceed 85% at 40℃
,the monthly average maximum of relative humidity in the wettest month does not
exceed 90%.
The effect of surface condensation caused by temperature changes on product performance should be taken into consideration.
