40
Nobeltec InSight Radar (IR2)
Operations Manual
The Vessel
Vessel name
Speed
Heading
Position
Radar Settings
Gain
Rain
Sea Clutter
Tune
IR rejection
Expand Targets
Selected Target
Type
Name
Range and Bearing
Course
Speed
CPA and TCPA
The Cursor
Bearing
Range
Position
The reported values in the Radar Console are effected by the settings in the Radar
tab of the program Options. Changing the side of the Radar Console from left to
right or turning it off altogether is also accomplished through the program Options.
Chapter 3
Working with IR2
