Noblelift PTE15N Pro - User Manual

45 pages

Save Page as PDF

To Next Page

Version 02/2024

PTE15N Pro&PTE20N Pro-SMS-003-EN

INSTRUCTION MANUAL

Electric Pallet Truck

PTE15N Pro (PTE33N Pro) / PTE20N Pro (PTE45N Pro)

WARNING

Do not use the pallet truck before reading and

understanding these operating instructions.

NOTE:

 Please check the designation of your

present type at the last page of this

document as well as on the ID-plate.

 Keep for future reference.

Questions and Answers

M
marcusgrahamAug 5, 2025
What to do if Noblelift PTE15N Pro Trucks not starts operating?
- C
  Chelsea HuangAug 5, 2025
  If your Noblelift Trucks won't start, first ensure the battery is fully charged and the main power plug is removed from the electrical socket. Check that the battery is correctly connected and that the fuses are in good condition. Also, verify that the emergency switch is not activated (turn it clockwise to deactivate). Make sure the tiller is in the braking zone and that the built-in charger is properly connected to the safety socket. If the battery is low, charge it.
A
Amber SantanaAug 19, 2025
Why Noblelift Trucks load can’t be lifted?
- R
  Robert StricklandAug 20, 2025
  If your Noblelift Trucks can't lift the load, it might be due to several reasons. Ensure that the load weight does not exceed the maximum capacity specified on the ID-plate. Check the battery level and charge it if it's low. Inspect the hydraulic oil level and refill if necessary. Also, look for any oil leakage and repair the cylinder's sealing if needed. Reduce the oil quantity if there is an excessive quantity of oil. If there is a lifting contactor failure, contact service support for replacement.

Summary

Foreword and Introduction

Foreword

Read this manual carefully and understand usage completely. Improper operation can create danger.

Copyright Information

The copyright remains with the company mentioned on the CE-certificate or company sticker.

Correct Application Guidelines

Use the electric pallet truck only according to this manual for intended applications.

Modification Guidelines

No modifications affecting safety or capacity without prior written approval.

Truck Description and Specifications

Overview of Main Components

Visual identification of the truck's key parts and their numbers.

Main Technical Data

Key technical specifications for the electric pallet truck models.

Safety Devices and Warning Labels

Description of safety devices and warning labels on the truck (Europe).

Identification Plate Details

Explanation of the information found on the truck's identification plate.

Warnings, Residual Risks, and Safety Instructions

Commissioning, Transporting, and Decommissioning

Commissioning Procedures

Steps to follow after receiving or for re-commissioning the pallet truck.

Lifting and Transporting

Guidelines for safely lifting the truck with a crane and securing it for transport.

Decommissioning Process

Procedures for storing the truck and final disposal for recycling.

Daily Inspection

Operating the Electric Pallet Truck

Parking Procedures

Safe methods for parking the electric pallet truck.

Lifting and Lowering Loads

Instructions on how to lift and lower loads with the pallet truck.

Travelling and Speed Control

Guidance on driving the truck and using speed control features.

Steering and Braking

How to steer the truck and understand its braking functions.

Malfunctions and Emergency Procedures

Steps to take for truck malfunctions and in emergency situations.

Pin-code Panel Operation

Introduction to Pin-code Panel

Overview of the electronic system for accessing the truck.

Access Codes and Functions

Details on using access codes and ID cards for truck operation.

Battery Safety, Charging, and Replacement

Lithium-ion Battery Description

Features and specifications of the lithium-ion battery pack.

Battery Decals and Identification

Description of various decals and the battery identification plate.

Battery Charging Procedures

Instructions and safety measures for charging the battery.

Battery Replacement

Step-by-step guide for replacing the battery in the truck.

Regular Maintenance Schedule

Maintenance Checklist

Comprehensive checklist of maintenance tasks with intervals.

Lubricating Points

Identification of points requiring lubrication with specified grease.

Hydraulic Oil Check and Refill

Procedures for checking and refilling the hydraulic oil.

Electrical Fuse Check

Information on locating and checking the electrical fuses.

Trouble Shooting Guide

Wiring Diagrams and Schematics

Electrical Diagrams

Detailed electrical circuit diagrams for truck models.

Hydraulic Diagram

Schematic representation of the truck's hydraulic system.

US Market Specialized Stipulations

Foreword and Compliance (US)

US market specific requirements, training, and safety compliance.

US Identification Plate Details

Explanation of the identification plate specific to the US market.

US Warning Labels Description

Description of warning labels and safety devices for the US market.

US Technical Data

Key technical specifications for the US market models.

Declaration of Conformity

Noblelift PTE15N Pro Specifications
