Wi-Fi module installation
Follow these steps to install the Wi-Fi module on the indoor unit:
1 . Open the front panel (see Fig.1)
2. Fix the Wi-Fi module inside the front panel.
a) In the models 9000 & 12000 btu (see Fig. 2):
b) In the models 18000
and 24000 btu the
Wi-Fi module is xed
inside the housing,
so it is necessary to
remove it
(see Fig. 3):
Fig. 1
Fig. 2
Fig. 3
