EN
2.4 Main Body
1
2
3
4
5
1. Protection Ring insulates heat
2. Rotary Control for function selection
3. Function Mark specic function
4. Base Mark to align functions
5. LED Light indicates a function is activated
2.5 Functions
The Rotary Control is used to select one of the 5 working functions or the OFF function. Once
connected to power, the Point LED Lights up above the Base Mark to show the cooker is con-
nected to power and in standby mode. By simply turning the Rotary Control body, a function
circle can be activated.
A function cycle has 2 parts: heating and cooling. Heating is indicated by the pulsating Ring LED,
and cooling is indicated by the sound of working fan inside the Main Body. Only when the tem-
perature of the heating surface drops to safe temperature (50ºC/ 122 ºF), the fan stops working
and the function cycle is complete.
OFF function
Cancel or stop any function cycle at any time
CBD Oil
Careful Bio-Decarb Oil function - infuse bio-active compounds into liquid oil
using herbs activated by the CBD Decarb function
≈180min / 100ºC / 212ºF
CBD Decarb
Careful Bio-Decarb function - decarboxylate the sensitive medicinal herbs that
requires lower temperature and longer time for activation
≈120min / 110ºC / 230°F
Decarb
General Decarb function - decarboxylate herbs
≈100min / 115ºC / 239°F
Oil
General Oil function - infuse bio-active compounds into liquid oil using herbs
activated by the general Decarb function
≈160min / 100ºC / 212ºF
Evaporation
Evaporation function - reduce the volume of infused liquid which has a boiling
point no higher than 100ºC / 212 ºF
Max. 102ºC / 215,6°F
2.6 Technical parameters and compliance
No light on:
Point LED on:
Ring LED on and pulsates:
Fan working:
Disconnected from power
Standby
Heating
Temperature above 50 ºC / 122 ºF
All-in-One Herb Cooker
EXT2020
74W
350ml
100-240V ~ 50/60Hz 2 A MAX
xx-xxxx
Product Name:
Model No.:
Power:
Volume:
Input power:
Compliance:
4
