Phone at a glance
8
■ Start screen
The start screen is home base and indicates your phone is in the standby mode.
Signal strength (1)—A higher bar indicates stronger signal.
Battery level (2)—A higher bar indicates more charge in the battery.
Menu (3)—Press the left selection key to select this option.
Contacts (4)—Press the right selection key to select this option.
■ Quick keys
In the standby mode, the 4-way scroll key functions as follows:
Scroll up: list contacts upwards
Scroll down: list contacts downwards
Scroll right: calendar
Scroll left: write message
■ Indicators and icons
Icon Indicates...
You have one or more text or picture messages. See "Read
and reply," page 30.
You are making or answering a call with the device. See
"Make a call," page 14.
You have one or more voice messages. See "Voice
messages," page 32.
Your phone keypad is locked. See "Keyguard," page 16.
Your phone is set to the silent profile. See "Profiles,"
page 41.
Simatai_User_Guide_nonRUIM_clean.fm Page 8 Wednesday, December 21, 2005 5:20 PM
