Nokia 2660 RM-292 - Page 13

13
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
2660 RM-292/RM-293
Page (30) ISSUE 1
Service Manual Level 1&2
7. Do the same on the left side.
8. Carefully unlock the A-COVER on the top.
9. Remove the A-COVER ASSY.
10. Gently open the connector of the LCD PM 128x160 with the
SS-93.
11. Carefully open the PWB FLEX connector. Avoid damaging
surrounding components.
12. Unlock the UI PWB ASSY with the SS-93.
