Nokia 446PRO - 1 Product Overview; Technical Specifications

446F
3
1. Product Overview
446F is a 19 inch monitor. The maximum resolution of 1600 x 1200 ma kes the monitor suitable for
PC, Macintosh and workstation applications in normally heated, ventialed and controlled office/home
environment. The monitor has an own power supply with nominal input voltage requirements from
90 V to 264 V.
1.1. Technical Specifications
Cathode Ray Tube 19” in diagonal 86˚ deflection angle..........
Antistatic, antireflex
Phosohor P22 medium short, Dot pitch 0.24 mm
Picture Size 354 mm x 265 mm with specified geometric distortion................
Maximum Picture Size 366 mm x 275 mm.......
Power Input Requirements Voltage 90-- 264 V, 50/60 Hz...
Current 1.8 A/100 V, 0.8 A/240 V
Power Dissipation < 130 W Normal Operation...........
<95WStand-- by
< 8 W Suspend
< 3 W Power off
Memory Locations 3 for factory preset display mode...........
18 for user adjusted display mode
Geometric Distortion The distance between bezel and active screen edge shall not vary.........
more than 2 mm in both vertical and horizontal dimensions
Luminance Min. 100 cd/m
2
(Nits) at center, with full white field.................
Video Input Input Signal: RGB, analog, max 0.7 V / 75 τ.................
Horizontal addressability: 1600 dots maximum
Vertical addressability: 1200 dots maximum
Synchronization Range Horizontal: 30 kHz to 107 kHz automatic......
Vertical: 50 Hz to 150 Hz automatic
Synchronization Signal Separate TTL , positive/negative.......
Composite TTL , positive/negative
Max. Dot Frequency 230 MHz.........
Temperature Operating: +10˚Cto+35˚C................
Packed: -- 3 0˚Cto+60˚C
Humidity Operating: 20% to 80 %...................
Packed: 5% to 90 %
Weight 25.3 kg net.....................
29.6 kg gross
Size, Tilt and Swivel
H
D
W
20
5
90
90
Dimensions
Monitor H 471 mm.................... ........
W 470 mm........
D 464 mm........
Package H 596 mm................... ........
W 600 mm........
D 571 mm........
