13. MECHANICAL PARTS LIST
ITEM
DESCRIPTION PART NO. QTY
M01 FRONT BEZEL 5642276700 1
M02 BACK BEZEL 5642276600 1
M03 SWIVEL BALL 5641407800 1
M04 BASE 5641407900 1
M05 CONTROL BUTTOM 5642837000 1
M06 HEAT SINK Q801 5646405000 2
M07 FBT SHIELD PLANE 5646435504 1
M08 HEAT SINK 5646428903 1
M09 HEAT SINK (AL) 5646405201 1
M10 HEAT SINK 5646405205 1
M11 DRVER CARD SHIELD-PLATE 5646246301 1
M12 AL SHIELD PLANE 5646438200 1
M13 LED WASHERS 5642024800 1
M14 COVER FOR CRT DRIVE SHIELD 5646246900 1
M15 METAL FRAME FOR CHASSIS 5648109000 1
M16 SHIELD FOR METAL CHASSIS 5646247300 1
M17 BRACKET METAL (L) 5648704600 1
M18 BRACKET METAL (R) 5648704601 1
M19 CLAMP SIGNAL CABLE (STEEL) 5648002600 1
M20 FBT FIXED 5648726300 1
M21 COPPER FOIL-CRT T= 0.5mm 5648006100 1
M22 DECORATING PLATE 5642414500 1
M23 PCB SPACER SUPPORT (LSD-9A) 5642670401 3
M24 FOOT PAD 5642024400 6
M25 CABLE SADDLE 5642665700 3
M26 LOGO (NOKIA) 5642414100 1
M27 SPONGE 5642018213 1
L01 HIGH VOLTAGE WARNING LABEL 5635572006 1
L02 S/N LABEL 5635580701 1
L03 BAR CODE BLANKNESS LABEL 5635562900 1
L04 MODEL LABEL 5635582900 1
L05 BAR CODE 5635582700 1
L06 TCO99 LABEL 5635582100 1
S01 SCREW, TS PHB+CWM5.0X22 7190561002 4
S02 SCREW PZP M4.0X14 7134251982 2
S03 SCREW PZP M4.0X10 7134251482 7
S04 SCREW PZS M3.0X10 7134161452 7
S05 SCREW BRB M3.0X10 7033161452 3
S06 SCREW BTBW M3.0X8 7000305012 20
S07 SCREW BTBW M3.0X6 7000305082 1
