Nokia 6300b RM-222 User Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
12.Sept.2007
11
Service Manual 6300 RM-217/ 6300b RM-222
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page
(33)
DISASSEMBLY - HINTS8.
1. Needed tools: SRT-6, metal tweezers, SS-93, SS-45 camera
removal tool, a straight bladed screwdriver, dental pick, bit
holder with a torx plus size 6 bit, a torque driver, DC plug
2. Always cover the windows with a protective lm.
3. Shift out the C-COVER.
4. Note! Before disassembling the phone, make sure that
the micro SD card has been removed. Remove both screws in
the order shown.
5. Remove the screws.
6. Unlock the plastic clips of the A-COVER with the SRT-6…
WWW.PCBOOK.IR

Nokia 6300b RM-222 Specifications

General

Brand	Nokia
Model	6300b RM-222
Category	Cell Phone
Language	English
