Nokia 6300b RM-222 User Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
12.Sept.2007
18
Service Manual 6300 RM-217/ 6300b RM-222
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page
(33)
ASSEMBLY - HINTS 9.
1. Assembly hints:
2. Keep in mind that the LABEL COVER ASSEMBLY with the
TYPE LABEL must always be assembled together with the
corresponding engine module.
3. Insert the LABEL COVER ASSEMBLY into the B-COVER as shown.
4. Carefully push all latches into their places.
5. Close the SIM lid.
6. Check the correct positioning of all these latches.
