Service Manual 6300 RM-217/ 6300b RM-222
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page
(33)
7. Insert the LED- and the SIDE- WINDOW. Note that they can’t
be interchanged.
8. Note that the IHF SPEAKER contacts belongs to their pads.
9. Secure all clips of the PLASTIC CHAMBER before going on.
10. Always use a new FLEX SHIELDING LID.
11. Mind the guiding tab while replacing the CAMERA.
12. Push it into its place.
