6303 Classic RM-443
Service Manual Level 1&2
20 CONFIDENTIAL
11. ASSEMBLY HINTS
1) Tighten the screws to the torque of 21 Ncm in
the order shown.
2) Tighten the screws to the torque of 21 Ncm in the
order shown.
Use the tweezers to assemble the
EARPIECE/RUBBER GASKET ASSY as shown. Make
sure that the rubber supports are correctly
positioned and aligned with the metal frame.
Do the same on the opposite side.
Issue 2 Copyright © 2009 NOKIA. All rights reserved.
