6. SERVICE TOOLS
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device merged into one package, developed
specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Internal Battery BLC-2C
Li-Ion 1000 mAh battery
Travel Charger ACP-8E
Travel Charger ACP-8X
Small and lightweight charger for fast charging of your
phone battery.
Headset HDS-3
Small and lightweight stereo headset for handsfree
functionality and listening to FM radio.
XCS-1
Service Cable is used to connect FLS-4S to FLA-29.
FLA-29
POS Flash Adapter is used in POS (Point of Sales) environment
for software updating. It provides controlled supply voltage
and necessary connections between the phone and the Flash
Device. It substitutes for the phone’s standard battery during
the software update.
TEST PIN
for Flash Adapter FLA-29
SS-4 Domesheet Assembly Jig
for Domesheet exchange
