Nokia 7390 Service Schematics

Customer Care / Service Operations / Content Creation Team
Condential Copyright © 2006 NOKIA Only for training purposes Version: 1.0 | 24.10.2006 | 7390 | Board version: 1TMA_12 | | Page 9(9)
Component nder
C2811 H8 C7524 G5 J3102 H8 N2200 I5 R3410 N4
B2200 J5 C2812 J8 C7525 G5 J 3103 H7 N2300 I2 R3411 M6
C2813 H6 C7543 F3 J3104 I7 N2301 H3 R3412 N6
C2000 O9 C2814 H7 C7544 F2 J3105 I7 N2600 F9 R3413 N6
C2002 Q8 C2815 H8 C7545 F2 J3110 I8 N3300 O7 R3417 N3
C2003 O9 C2816 H6 C7547 F2 J3111 J8 N3301 K3 R3418 M4
C2004 P8 C2817 H8 C7548 F2 J3112 I7 N3400 N5 R3419 L3
C2005 Q8 C2818 J6 C7549 F3 J3113 I7 N3401 L4 R4801 D6
C2006 P8 C2819 H8 C7550 F2 J3114 J7 N3402 K4 R4803 D6
C2007 Q8 C2820 I8 C7553 E3 J3115 I7 N4800 E3 R4804 F2
C2008 Q7 C2821 J7 C7580 G8 J3116 I7 N4801 E2 R4805 E2
C2009 Q7 C2822 H6 C7581 G8 J3117 I7 N6050 M3 R6002 M2
C2012 O9 C2823 J8 C7582 G9 J3118 H7 N7505 F8 R6005 O8
C2013 P7 C3100 J8 C7583 G8 J3119 H7 N7520 F5 R7501 F8
C2014 O7 C3300 O7 C7586 G7 J3120 I7 N7540 E2 R7502 G8
C2070 N2 C3302 O7 C7587 F7 J3400 I6 N7541 G2 R7503 G7
C2106 F9 C3303 O8 C7590 E6 J3412 L4 N7590 E6 R7509 E8
C2107 G9 C3304 M8 C7591 E6 J3413 K4 R7521 G5
C2111 G9 C3305 N8 C7801 C2 J3418 H6 R2001 O7 R7522 F7
C2112 H9 C3307 K2 J3500 Q9 R2002 P7 R7528 E5
C2117 I9 C3308 K3 D2800 I7 J6040 H6 R2003 Q8 R7529 E5
C2118 I9 C3309 L2 D2801 I7 J6041 H6 R2006 P8 R7530 E5
C2119 I9 C3310 K2 D3400 L5 J6042 I6 R2007 P3 R7541 G2
C2120 I9 C3311 L2 D6000 Q3 R2009 P3 R7543 F2
C2124 I9 C3312 L3 L2001 Q8 R2010 O9 R7544 F2
C2126 I9 C3400 M4 F 2000 Q9 L2002 Q7 R2011 O7 R7560 G3
C2127 I9 C3401 N4 L2003 P7 R2060 I2 R7800 D2
C2201 I5 C3403 M5 G2200 J4 L2005 P7 R2071 O8 R7801 C2
C2202 H4 C3404 N5 G7501 E8 L2101 G9 R2119 F9 R7810 D3
C2203 I4 C3406 O5 L2102 F9 R2121 J9
C2205 I4 C3407 O5 J2005 P4 L2103 F9 R2124 J9 T7502 E5
C2211 H5 C3410 N6 J2006 P3 L2104 H9 R2151 M7 T7580 G6
C2213 I5 C3411 K5 J2007 P2 L2107 H9 R2152 K9
C2215 I5 C3412 M6 J2010 N7 L2110 G9 R2153 K9 V2160 M7
C2216 J5 C3415 M4 J2011 N8 L2111 H9 R2155 M7 V3300 L2
C2217 I4 C3416 N4 J2012 N8 L2202 H4 R2160 M7 V3301 M2
C2220 H4 C3417 L4 J2060 I3 L2205 H4 R2200 I4
C2222 H5 C3418 L4 J2200 I4 L2211 N3 R2210 K7 X2001 Q8
C2225 J5 C3419 K5 J2201 H4 L2212 O3 R2211 K7 X2002 Q3
C2226 H5 C3420 K4 J2202 I6 L2301 H3 R2212 I4 X2061 Q2
C2227 I5 C3421 K4 J2203 I4 L2302 H2 R2300 J2 X2070 O3
C2228 H5 C3422 K4 J2204 H7 L2304 H3 R2303 H3 X2400 L7
C2231 H4 C3424 N6 J2205 H4 L2400 K8 R2400 K8 X2700 E5
C2232 H5 C3425 N4 J2206 I2 L2401 L8 R2401 H4 X3300 N7
C2300 H3 C3428 N6 J2207 I4 L3300 O7 R2402 L8 X3301 P3
C2301 I2 C3429 N6 J2208 I4 L3301 P7 R2600 E9 X3302 P3
C2302 I2 C3500 Q9 J2209 I4 L3302 M8 R2800 I6 X3500 M8
C2303 J2 C3501 N8 J2210 I5 L3303 K2 R2801 H7 X4800 E4
C2304 I2 C3502 N8 J2211 I4 L3400 M4 R2802 H7 X6000 O8
C2307 J3 C3503 O8 J 2212 I5 L3401 M4 R2803 J6 X6001 O7
C2309 H3 C3504 O8 J2213 J7 L3402 K5 R2804 J8 X7800 D3
C2312 J3 C3505 P8 J2214 I6 L3403 L4 R2900 J8 X7801 C3
C2314 I3 C4800 F3 J2215 I4 L3404 M4 R2901 J8 X7802 C2
C2405 K9 C4801 E3 J2216 I2 L3405 N4 R2902 J8 X7803 Q7
C2406 K9 C4803 E3 J2217 J2 L3500 Q8 R2903 J8 X7804 O3
C2407 L8 C4805 E6 J2218 J5 L7500 F7 R2904 I8 X7805 Q2
C2408 L8 C4806 E2 J2219 J3 L7501 F7 R2905 I8
C2409 M8 C4807 F2 J2220 I4 L7502 E7 R2906 H8 Z2000 P8
C2600 E9 C4808 E2 J2221 I4 L7503 G7 R2907 H8 Z2001 P4
C2601 E9 C6000 P3 J2230 J7 L7506 E8 R2908 J5 Z2002 Q8
C2602 E9 C6001 P3 J2300 I4 L7510 E4 R3300 J6 Z2100 I4
C2700 F6 C6003 P4 J2301 J2 L7526 G6 R3301 J7 Z2403 J9
C2701 F6 C6004 P4 J2302 J3 L7540 G3 R3303 L2 Z2404 K7
C2702 E6 C6005 Q2 J2305 I3 L7550 F2 R3304 L3 Z2405 K7
C2703 E6 C6006 P3 J2306 J2 L7588 E7 R3305 L3 Z2406 K7
C2704 E3 C6050 M2 J2307 J2 L7589 E7 R3308 L2 Z4800 E3
C2800 I6 C6051 M3 J2308 J2 L7590 E6 R3310 L3 Z7501 F6
C2801 H8 C6052 M3 J2700 G6 L7591 G2 R3311 L2 Z7503 F6
C2802 H6 C7500 F 8 J2701 G4 L7592 E6 R3312 L3 Z7504 F7
C2803 H8 C7507 E7 J2702 G5 L7802 C2 R3313 M2 Z7521 E5
C2804 H8 C7513 F 8 J2703 G5 L7803 C2 R3314 M2 Z7540 E3
C2805 H6 C7518 G7 J2704 G4 R3315 L2 Z7541 F3
C2806 I8 C7519 F8 J2800 I9 N2000 Q8 R3320 O8 Z7580 G6
C2807 J7 C7520 F8 J2801 I8 N2001 P8 R3401 N4 Z7582 E7
C2808 I8 C7521 G4 J2803 J2 N2101 H9 R3405 M5
C2809 J6 C7522 F6 J3100 I8 N2160 M7 R3408 N4
C2810 J6 C7523 E4 J3101 H8 N2161 M7 R3409 N4
R
B
C
N
L
D
F
G
J
T
V
X
Z
Bottom
TOP
MAIN PWB
MAIN PWB
SIM reader
IRDA
Mini -USB
connector
AV
connector
BTHFM
OMAP
SDRAM
RAP3GS
Combo memory
AHNEUS
GSM
Power
Amplifier
AVILMA
WCDMA
Power
Amplifier
BETTY
Micro SD reader
Board to Board connector flex foil
Camera conn.
B to b conn. keyboard
