Nokia 7600 - Page 8

NMM-3 Company Confidential
5 - Disassembly Instructions CCS Technical Documentation
Page 5-8 Copyright  2003 Nokia Corporation. Issue 1 (11/2003)
Company Confidential
21. Lever out WCDMA Antenna from
B-cover.
22. Using a charger plug remove the
DC Jack.
23. Remove Vibra Motor, taking care
not to damage the spring contacts.
24. Unlock the side snaps to remove
the IT Window.
21
22
23
24
