Define Internet connections
20
Copyright © 2006 Nokia. All rights reserved.
■ WLAN connection
To set up a WLAN connection, do the following:
1. In the Connection setup: Name and type dialog, define the following
settings:
Connection name — Enter a descriptive name for the connection.
Connection type: — Select WLAN.
2. Tap Next. The device asks whether you want to scan for available
WLAN networks. Tap Yes to start the scan, or No to skip it.
If you select Yes, all available WLAN networks are shown after the
scan with information about each WLAN connection:
• Security level of WLAN connection:
— No security (for example, a public access point in an
airport)
— Medium security (wired equivalent privacy (WEP)
authentication)
— High security (Wi-Fi protected access (WPA)
authentication, including WPA1 and WPA2).
The security level of the network affects the settings that are
shown when you tap Next.
• Name of the WLAN network
• WLAN signal strength
• if the WLAN network is already defined for an Internet
connection setup that you have saved in the device
3. Tap Finish to save the settings. To define advanced settings, tap
Advanced.
Tip: You may need to define advanced settings, for example, if
your Internet access point requires the use of proxies.
The following settings are shown when you edit and existing WLAN
connection, or when you skip the scan for WLAN networks in step 2:
Network name (SSID) — Enter the name of the WLAN network. If you are
the administrator of the network, ensure that the name of the network
To Next Page
