5.3 NO HEADSET FUNCTION
No headset
function
ok ?
Change
System
Connector
ok ?
Send to
Service Center
END
Yes
No
No Yes
Check spring
contacts of the
System
Connector
- connection
- optical condition
- mech. condition
- corrosion
Check and
clean pads of
the System
Connector
(LA5 bottom
side).
