Nokia C1-02 Service Manual

Nokia C1-
02
RM-643 / RM-644
Service Manual Level 1&2
6 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0
3. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against
static
electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the product
is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be
damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD
Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia C1-02 Specifications

General

Display	TFT, 65K colors
Battery	Removable Li-Ion 1020 mAh battery (BL-5C)
Weight	78 g (2.75 oz)
SIM	Mini-SIM
Network	GSM 900 / 1800
Bluetooth	No
Radio	FM radio
USB	No
Status	Discontinued
Stand-by	Up to 504 h
Talk time	Up to 10 h 40 min
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	No
Browser	WAP 2.0/xHTML
Games	Yes
Camera	No
Dimensions	108 x 45 x 13.8 mm
Announced	2010, June
Colors	Black, Red, Blue
Messaging	SMS, MMS, Email
Java	Yes
