Nokia C2-02 Service Manual

Nokia C2-02 /C 2-07 (RM-692/RM-693)
Nokia C2-03 /C 2-06/C 2-08 (RM-702)
L1L2 Service Manual
3
Co nf id e nt ial | Co p yrig ht © 2011 Nokia | A ll rights reserved
V e rs ion 1 .0
CHANGE HISTORY
Status
Version No.
Date
Comments
Approved
1.0
22.06.2011
First approved version
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note tha t NOKI A provides also other
guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and
comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
Nokia Care Academy
service.manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.

Nokia C2-02 Specifications

General

Display type	TFT
Display diagonal	2.6 \
External display	No
Display resolution	240 x 320 pixels
Display number of colors	65536 colors
Flash memory	2048 MB
Internal memory	10 MB
Maximum memory card size	32 GB
Photo effects	Negative film
White balance	Auto, Daylight, Fluorescent, Incandescent
Image formats supported	JPG
Rear camera resolution (numeric)	2 MP
Networking type	GSM/EDGE
Operating frequency	850/900/1800/1900 MHz
USB 2.0 ports quantity	1
Headphone connectivity	3.5 mm
Data network	EDGE, GPRS, GSM
GSM bands supported	850, 900, 1800, 1900 MHz
SIM card capability	Single SIM
GPRS multislot class	12
Form factor	Slider
Embedded games	6
Personalization	Menu, Shortcuts, Themes
Phonebook capacity	1000 entries
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, To-do list
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Video compression formats	3GP, H.263, MP4, WMV
Video capture resolution (max)	176 x 144 pixels
Ringer type	Polyphonic
Audio formats supported	AAC, AMR, MIDI, MP3, WAV
Operating system installed	-
Battery type	BL-5C
Talk time (2G)	5 h
Battery capacity	1020 mAh
Standby time (2G)	600 h
Continuous audio playback time	37 h
Volume control	Digital
Bluetooth version	2.1+EDR

Weight and Dimensions

Depth	103 mm
Width	51.4 mm
Height	17 mm
Weight	115 g
