Component Parts
Advanced Active Holder MCC–1
The holder allows the phone to be firmly located in a convenient position.
The holder is attached to the vehicle’s interior using the swivel mount
HHS–9. The mounting must be secured with a screw (included with
HHS–9). The screw recess can then be covered with the NOKIA logo
plate.
Advanced HF Unit HFU–2
The handsfree unit enables the phone to operate in handsfree mode.
The unit is attached to the vehicle interior using the mounting plate
MKU–1. The mounting must be secured with a screw (included with
MKU–1). A temporary installation can be achieved using installation belts
(not supplied).
Power is supplied from the vehicle’s battery via the power cable PCH–4J.
The handsfree unit provides the power supply to the phone via the sys-
tem connector.
The HF microphone HFM–8, connects to the MIC socket. And the HF
speaker HFS–12, connects to the socket.
Mounting Plate MKU–1 and Swivel Mount HHS–9
MKU–1 is a fixed position mounting plate; HHS–9 is a swivel mount which
allows for adjustable fixing. The two mounting plates are interchangeable.
HF Microphone HFM–8
The HF microphone connects directly to the handsfree unit ( MIC socket).
Insert the plug into the MIC socket and twist 90° to lock firmly in place.
HF Speaker HFS–12
The HF speaker connects directly to the handsfree unit ( socket).
Insert the plug into the socket and twist 90° to lock firmly in place.
