Nokia CK-100 Quick Installation Guide

ENGLISH
If you want to use the loudspeaker
SP-3 for calls, use the power cable
PCU-4 instead of the ISO cable. For
instructions, see the user and
installation guide on the CD.
You can connect the car kit to a
loudspeaker with an impedance of at
least 2 ohms. The optimal impedance
is 4 ohms.
Use the car kit amplifier for
calls and music
Make the connections as shown in
Figure 1 to use the built-in amplifier
of the car kit for calls and music
played on a device that supports the
A2DP Bluetooth profile.
After you have connected the ISO
cable, connect the input device CU-11
and the microphone MP-2 to the
hands-free unit.
Use the car kit amplifier for
calls and the car radio
amplifier for music
Make the connections as shown in
Figure 2 to use the amplifier and
equaliser of your car radio for music
played on a device that supports the
A2DP Bluetooth profile. The built-in
amplifier of the car kit is used for calls.
Cut the loop indicated with scissors in
the figure.
Connect the stereo outputs of the
hands-free unit to the AUX input of
the car radio. Use an appropriate cable
specific to your car radio (this cable is
not supplied with the car kit).
After you have connected the ISO
cable and the stereo output cable,
connect the input device CU-11 and
the microphone MP-2 to the hands-
free unit.

Nokia CK-100 Specifications

General

Compatible products

Nokia 2600 Classic Nokia 2630 Nokia 2760 Nokia 3110 Classic Nokia 3120 Nokia 3120 Classic Nokia 5000 Nokia 5200 Nokia 5300 XpressMusic Nokia 5310 XpressMusic Nokia 5610 XpressMusic Nokia 5800 XpressMusic Nokia 6085 Nokia 6103 Nokia 6110 Navigator Nokia 6111 Nokia 6120 Classic Nokia 6121 Classic Nokia 6131 Nokia 6220 Classic Nokia 6230 Nokia 6230i Nokia 6233 Nokia 6267 Nokia 6280 Nokia 6290 Nokia 6300 Nokia 6500 Classic Nokia 6500 Slide Nokia 6555 Nokia 6600 fold Nokia 7373 Nokia 7500 Prism Nokia 7610 Nokia 8600 Luna Nokia 8800 Nokia 8800 Arte Nokia 9300i Nokia E50 Nokia E51 Nokia E60 Nokia E61 Nokia E61i Nokia E65 Nokia E66 Nokia E70 Nokia E71 Nokia E90 communicator Nokia N70 Nokia N73 Nokia N76 Nokia N77 Nokia N78 Nokia N79 Nokia N80 Nokia N82 Nokia N93 Nokia N93i Nokia N95 Nokia N95 8GB Nokia N96

Connectivity technology

Wireless
