E55 RM-482, RM-483
Service Manual Level 1&2
23 CONFIDENTIAL
5
6
Align the LCD using the corner marking lines. Remove the protection foil.
7
8
Attach the FRAME ASSY to the B-COVER starting
from the side where the keys are.
Attach the FRAME ASSY in place by pressing the
clip as shown in the picture.
Issue 1 Copyright © 2008 NOKIA. All rights reserved.
