11.3 Assembling the A-COVER
Before attaching the old/used A-COVER, check that the screw towers (shown in the picture) are
intact and use the correct moment when tightening the screws.
11.4 Screw order and torque
Tighten the screws to the torque of 15 Ncm in the
order shown.
Tighten the screws to the torque of 5 Ncm in the
order shown.
