E55 RM-482, RM-483
Service Manual Level 1&2
13 CONFIDENTIAL
10. DISASSEMBLY INSTRUCTIONS
Note: Nokia E52 has been used in the pictures of the disassembly instructions but these
instructions are valid as such also for Nokia E55. The only difference between E52 and E55
is the different keyboard.
1
2
Slide the BATTERY COVER release button to the
direction shown in the picture.
Lift up the BATTERY COVER and…
3
4
…remove it. Remove the battery.
Issue 1 Copyright © 2008 NOKIA. All rights reserved.
