Nokia E75 Service Manual

Nokia E75 RM-412/RM-413
Service Manual Level 1&2
3 Confidential  Copyright © 2009 NOKIA  All rights reserved Version 1.0 ISSUE 1
1. CHANGE HISTORY
Status Version No. Date Comments
Approved 1.0 3.2.2009 Approved version
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry
out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service
suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance
documents (e.g. Service Bulletins) for service suppliers, follow these regularly and comply with the
given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
CMO Operation & Logistics
Training and Vendor Development
Multimedia Creation & Support
mailto:Service.Manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified, so
watch always out for the newest version.

Nokia E75 Specifications

General

Panel type	TFT
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Internal memory	50 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	16 GB
Internal storage capacity	- GB
Flash type	LED
Sensor type	CMOS
White balance	Auto, Daylight, Fluorescent, Incandescent
Front camera type	Single camera
Rear camera resolution	2048 x 1536 pixels
Video capture resolution (max)	640 x 480 pixels
Rear camera resolution (numeric)	3.2 MP
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, To-do list
HDMI ports quantity	0
Headphone connectivity	3.5 mm
Text prediction system type	T9
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Voice codecs	EFR, FR
Audio formats supported	AAC, AMR
Video formats supported	-
Ringer type	Polyphonic
Talk time (2G)	5.3 h
Talk time (3G)	4.3 h
Battery capacity	1000 mAh
Standby time (2G)	280 h
Standby time (3G)	270 h
Continuous audio playback time	25 h
Form factor	Slider
Product color	Black, Silver
Keyboard layout	QWERTY
2G standards	EDGE, GPRS, HSCSD
Data network	csd, wcdma
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Bluetooth profiles	A2DP, AVRCP, BIP, BPP, DUN, FTP, GAP, GAVDP, GOEP, HFP, HID, HSP, OPP, PBAP, SAP, SPP
SIM card capability	Single SIM
Mobile network generation	3G
Processor frequency	- GHz
Platform	Symbian
Operating system installed	Symbian OS
Subscription type	No subscription
Specific absorption rate (SAR) value (EU)	- W/kg

Weight and Dimensions

Depth	14.4 mm
Width	80 mm
Height	111.8 mm
Volume	69 cm³
Weight	139 g
