19. …in the middle…
20. …and these longer ones…
21. …at both edges of the A-COVER ASSEMBLY.
22. Set the correct torque.
23. Apply the correct torque in the order shown.
24. Align the new LOGO PLATE rst. Then smooth it down evenly.
