Nokia E90 - Page 24

24
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
E90 RA-6
Page (51) ISSUE 1
Service Manual Level 1&2
25. Unscrew this 2 Torx Plus size 4 hinge screws.
26. Discard them. Do not use them again when reassemble.
27. The upper assembly can be removed now.
28. The WLAN ANTENNA MODULE can be removed.
29. Unscrew these 3 Torx Plus size 4 screws in the shown
order.
30. Discard them, do not use them again.
