E90 RA-6
Page (51) ISSUE 1
Service Manual Level 1&2
31. Mind the cleanness of the camera and window when
replacing the ANTENNA COVER, beginning at the hinge side.
32. Close this clip rst…
33. ...then the clip on the edge…
34. ...followed by the 2 snaps at this side.
35. The last clip is located close to the CAMERA BUTTON. Click it
into its place slightly.
36. Replace the BATTERY COVER.
