Nokia Lumia 525 Service Manual

Service Manual Level 1 and 2
Nokia Lumia 525
RM-998
Version 1.0
Product controls and interfaces
3
4
5
6
11
12
13
14
7
8
9
10
16
15
10 — Camera
9 — Micro USB connector
8 — Microphone
7 — Search key
6 — Back key
5 — Home key
4 — Touch screen
3 — Ambient light & Proximity
sensors
1 — 3.5 mm AHJ connector
2 — Earpiece
11 — Volume keys
12 — Power/Lock key
13 — Camera key
14 — Loudspeaker
15 — GNSS antenna
16 — Cellular antenna
