Nokia Lumia 610

Service Manual Level 1 and 2
Nokia Lumia 610
RM-835 RM-836
Version 1.0
Product controls and interfaces
3
5
6
7
8
4
2
1
14
15
16
9
11
10
12
17
13
8 — Start key
7 — Touch screen
6 — Ambient light &
Proximity sensor
5 — Earpiece
4 — Secondary microphone
3 — Micro USB connector
2 — Nokia AV 3.5 mm connector
1 — Strap holder
9 — Back key
10 — Search key
11 — Microphone
12 — Camera
13 — Camera flash
14 — Volume keys
15 — Power/Lock key
16 — Camera key
17 — Loudspeaker
