Nokia Lumia 620

Service Manual Level 1 and 2
Nokia Lumia 620
RM-846
Version 1.0
Product controls and interfaces
2
4
5
7
6
1
3
13
14
15
16
8
10
9
11
12
17
14 — Power/Lock key
15 — Camera key
16 — Loudspeaker
17 — Antenna area
9 — Micro USB connector
8 — Search key
7 — Start key
6 — Back key
5 — Touch screen
4 — Earpiece
3 — Ambient light & Proximity
sensors
2 — Nokia AV 3.5 mm connector
1 — Secondary microphone
10 — Microphone
11 — Camera flash
12 — Camera
13 — Volume keys
v1.0
©2012 Nokia | Nokia Internal Use only | All Rights Reserved.
