Nokia Lumia 710

Service Manual Level 1 and 2
Nokia Lumia 710
RM-803, RM-809
Version 1.0
Product controls and interfaces
1
4
6
9
2
3
5
15
16
7
10
8
11
12
17
13
14
Ver. 1.0
9 — Start key
8 — Search key
7 — Back key
6 — Touch screen
5 — Ambient light &
proximity sensors
4 — Earpiece
3 — Micro USB connector
2 — 3.5 mm AHJ connector
1 — Power key / Key lock button
10 — Microphone
11 — Strap holder
12 — Camera
13 — LED flash
14 — Secondary microphone
15 — Volume keys
16 — Camera key
17 — Loudspeaker
©2011 Nokia | Confidential | All Rights Reserved.
