Nokia Lumia 820 User Manual

Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
Make sure the phone is switched off.
1. With the back of the phone facing you, place your thumb on the back of the phone next to the
camera lens.
2. At the top left corner, put your fingernail in the seam between the screen frame and the back cover.
Bend the cover until a side seam opens slightly.
3. Repeat on the other corner, and remove the cover.
4. If the battery is in, lift it out.
5. Push the SIM into the card slot until it locks into place. Make sure the contact area is face down.
© 2014 Microsoft Mobile. All rights reserved.
8

Nokia Lumia 820 Specifications

General

Processor	Dual-core 1.5 GHz Krait
RAM	1 GB
Internal Storage	8 GB
Expandable Storage	microSD, up to 64 GB
Front Camera	VGA
Dimensions	123.8 x 68.5 x 9.9 mm
Weight	160 g
Colors	Black, Gray, Red, Yellow, White, Blue, Violet
Network	GSM / HSPA / LTE
SIM	Micro-SIM
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band
Bluetooth	3.1, A2DP, EDR
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
USB	microUSB 2.0
Display	4.3 inches, AMOLED, 480 x 800 pixels
Rear Camera	8 MP, Carl Zeiss optics
Battery	1650 mAh, removable
Operating System	Microsoft Windows Phone 8
Radio	FM radio
