Nokia Lumia 830 User Manual

Note: Turn the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. Switch your phone off.
2. At the bottom of the phone, put the nail of your index finger in the small slot between the metal
frame and the back cover. Press the middle of the back cover, bend the cover open, and remove it.
Do not use any sharp tools, as they may damage the screen.
3. If the battery is in, lift it out.
4. Slide the nano-SIM card into the SIM slot with the metal contact area down until you hear a click.
© 2015 Microsoft Mobile. All rights reserved.
6

Nokia Lumia 830 Specifications

General

Display Size	5.0 inches
Resolution	720 x 1280 pixels
Display Type	IPS LCD
Processor	Qualcomm Snapdragon 400
CPU	Quad-core 1.2 GHz Cortex-A7
RAM	1 GB
Internal Storage	16 GB
Expandable Storage	microSD, up to 128 GB
Rear Camera	10 MP
Front Camera	0.9 MP
Battery Capacity	2200 mAh
Dimensions	139.4 x 70.7 x 8.5 mm
Weight	150 g
Network	GSM / HSPA / LTE
SIM	Micro-SIM
Bluetooth	4.0, A2DP
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Radio	FM radio
USB	microUSB 2.0
Sensors	Accelerometer, gyro, proximity, compass
Battery Type	Li-Ion (removable)
Operating System	Microsoft Windows Phone 8.1
Colors	Black, White, Green, Orange
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band
