Nokia N8–00

Nokia N8-
00
RM-596
Service Manual Level 1&2
14 Confidential | Copyright © 2010 Nokia | All rights reserved Version 3.0
7) Lift up the shown end of the BATTERY LID. Release
also the other end by pulling it into direction shown.
8) Now the BATTERY LID can be removed.
9) Pull out and remove the BATTERY by using the
BATTERY PULL-OUT TAPE.
10) Open the HDMI HATCH.
11) Unscrew the Torx+ size 5 screw. Do not use it
again. Discard it.
12) Remove the TOP COVER by pushing it from the
back side to the direction shown.
