Nokia N82 - Product Contorls & Overview

6
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
N82 RM-313/RM-314
Page (22)
ISSUE 1
Service Manual Level 1&2
PRODUCT CONTORLS & OVERVIEW7.
Ver. 1.0
N82 RM-313/ RM-314 Product Controls & Interfaces
Stereo speaker with
3D sound Effect
Micro USB port
Zoom/volume key
End key
Clear key C
Numeric keypad
Multimedia key
Charger connector
Memory card slot for a
compatible microSD card
Xenon flash
Main camera for high
resolution (up to 5Mpix)
image capture and video
recording
Camera activation switch with
lens cover
Call key
Power key
Light sensor
Nokia AV Connector (3.5mm) for
compatible headsets, headphones,
and TV-out cables
Secondary camera
with lower resolution
Selection keys
Menu key
5-Way key
Hereinafter referred to as the scroll key
Microphone
Review key
2-stage capture key for
autofocus, still image
capture, and video
recording
Stereo speaker with
3D sound Effect
